271646102
ETIMAT P6 3p+N C16 Miniature circuit breaker
- ETI Code:
- 271646102
- Application:
- EN/IEC 60898
- Rated current:
- 16 A
- Tripping characteristic:
- C
- Number of poles:
- 3+N
- Short circuit capacity:
- 6 kA
- Voltage type:
- AC
- Rated impulse withstand voltage Uimp:
- 6 kV
- Rated AC voltage:
- 240 V
- Rated frequency:
- 50/60 Hz
- Rated cross section:
- 1-25 mm²
- Standards:
- EN/IEC 60898
- Function:
- MCB
7 Documents
6 Logistics
Product
- Net weight of the product
- 480 kg
- Net width
- 72 mm
- Net height
- 90.1 mm
- Net depth
- 74.47 mm
- Stock unit of measure
- pcs
Transport Packaging
- Customs tariff
- 85362010
