002646006
CH22x58 SRF60-II/600V Fuse link
- ETI Code:
- 002646006
- Product group:
- Special purpose fuses
- Product subgroup:
- SRF
- Catalogue Group:
- Special purpose fuses
- Catalogue Subgroup:
- TVSS Protection Fuse - SRF
- Type description:
- CH
- Fuse type:
- CH
- Size:
- 22x58
- Overvoltage Category:
- II
- Surge Rating for SRF Fuse:
- 60,000 A
- Rated AC voltage:
- 600 V
- Breaking capacity AC:
- 200 kA
- Application:
- These fuses are intended for installation in series with TVSS devices
- Operating joule integral (A2s):
- 247,180
- Prearcing joule integral (A2s):
- 133,630
- Standards:
- Comply with the applicable requirements in UL 248-1 Low Voltage Fuses- Part1, General Requirements.
5 Documents
22 Logistics
Product
- EAN code for a single product
- 3838400063199
- Net weight of the product
- 52 g
- Net width
- 22.2 mm
- Net height
- 58 mm
- Net depth
- 22.2 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 10 pcs
- EAN code for a basic packaging
- 3838895578437
- Basic packaging weight
- 0.534 kg
- Basic Packaging Dimensions Height
- 0.024 m
- Basic Packaging Dimensions Width
- 0.148 m
- Basic Packaging Dimensions Depth
- 0.074 m
- Basic packaging volume
- 0 m³
Transport Packaging
- Transport packaging quantity
- 440 pcs
- EAN code for a transport packaging
- 3838895578444
- Transport packaging weight
- 23.846 kg
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- Transport packaging volume
- 0.017 m³
- Pallet quantity
- 22,880 pcs
- Customs tariff
- 85361090
3 ETIM
- Size
- 22x58 mm
- Breaking capacity
- 200 kA
- Utilization category
- Other
ETIM Classification – Version 9.0
